Swisspearl (Cembrit) Cemsix fully compressed fibre cement sheet – the traditional 6 inch profile – can be used on new buildings and as a replacement sheet for existing farm and equestrian buildings, already incorporating 6 inch profile. Cemsix sheeting is the ideal material for all single skinned agricultural and equestrian buildings.
Cemsix fully compressed corrugated sheets are denser than semi compressed alternatives and better able to withstand abrasion and wear.
Available in natural grey, the Cemsix system is covered by BBA Agrément Certificate 03/4049 and is guaranteed for 30 years’ durability and 10 years’ colour stability.
Cemsix ventilation accessories have been designed to accommodate differing approaches to ventilation according to the produce the building will be used for. The ventilation options allow compliance with the latest requirements for animal welfare.
In addition to over 100 years’ experience manufacturing fibre reinforced cement roofing and cladding products, Cemsix comes with all the product quality and environmental management accreditations you would expect. Swisspearl corrugated sheets is a high-quality fibre cement product used as roofing and cladding on agricultural and industrial buildings.
Colour Disclaimer. Please note that although we do our best to make sure that the colours displayed on our website are accurate, the actual colours may vary due to inconsistencies with display monitors.
LARGE ORDER DISCOUNTS AVAILABLE
MCS Roofing & Cladding Supplies is a family run business and we pride ourselves on providing excellent customer service. If you would like any help or assistance, please don’t hesitate to call us on 01538 398 708 or email info@mcsroofing.co.uk where our friendly team will be waiting to help you.
overview
- Material: Fibre cement
- Fire protection class: A1
- Mechanical strength: Class C1X
- Avg SQM weight: 13.9 kg
- Fixing: Steel or timber with self-drilling screws
TECHNICAL DATA
| Overall Width: | 1086mm |
| Net Covering Width: | 1016mm |
| Thickness: | 6.0mm |
| Depth of Profile: | 54mm |
| Pitch of Corrugations: | 146.5mm |
| Side Lap: | 70mm |
| Minimum End Lap: | 150mm |
| Maximum Purlin Centres: | 1375mm |
| Maximum Rail Centres: | 1825mm |
| Maximum Unsupported Overhang: | 350mm |
| Minimum Roof Pitch: | 5° |
| Density (nominal): | 1700kg/m3 |
| Approximate weight of roof as laid, with 150mm end laps, single skin, including fixings: | 17kg/m2 |
